The Ikon IBB49-2G-24 is a two-door back bar bottle cooler with swing glass doors that holds 33 to 40°F (0.5 to 4°C) and stores 48 x 6 pks of 12 oz. cans or 216 12 oz. bottles. It uses an electronic thermostat with a digital LED temperature display, a mono-block design, R-290 natural refrigerant and CFC-free foam insulation, and runs on 115V with a NEMA 5-15P plug and 10 ft cord.
The top is 430 stainless steel, the interior is 430 stainless steel with a 304 stainless steel floor, and the exterior is finished in heavy-duty, wear-resistant black paint. Doors have lock and key, and the magnetic gaskets replace without tools. Each door has two adjustable, heavy-duty epoxy-coated wire shelves, and the frame is stainless steel.
The unit rolls on 4" casters that are standard, with two locking at the front, and is designed to operate in ambient temperatures of 40°F to 90°F.
| Doors | 2 swing |
|---|---|
| Door Locks | Lock and key |
| Shelves | Two adjustable epoxy-coated wire shelves per door |
| Temperature Range | 33 to 40°F (0.5 to 4°C) |
| Electrical | 115V / 60Hz / 1 Ph, NEMA 5-15P plug, 10 ft cord |
| Amps | 3 |
| Horsepower | 0.40 HP |
| Refrigerant | R-290 (natural |
| refrigerant | ) |
| Capacity | 48 x 6 pks of 12 oz. cans or 216 12 oz. bottles |
| Storage Capacity (manual) | 10.45 cu ft |
| Exterior Dimensions (W x D x H) | 49.1" x 24.4" x 41.7" |
| Interior Dimensions (W x D x H) | 36" x 20.01" x 29.37" |
| Top | 430 stainless steel |
| Exterior | Heavy-duty, wear-resistant black paint |
| Interior | 430 stainless steel with 304 stainless steel floor |
| Casters | 4" casters, two lockable at the front |
| Ambient Operating Range | 40°F to 90°F ambient |
| Ship Weight | 307 lb |
