The Kool-It Infinity KIN23F-HC is a 1-door reach-in freezer that holds -8°F to 0°F (-22°C to -18°C) and uses R290 refrigerant with foam insulation. It has a self-closing, locking door that stays open at 90 degrees, and 3 adjustable, heavy-duty epoxy coated wire shelves per door.
The exterior is 430 stainless steel, the interior is 201 stainless steel and the interior floor is 304 stainless steel. The magnetic door gasket can be replaced without tools, and 4" casters, lockable at the front, are standard.
Temperature is managed by an electronic thermostat with a digital LED temperature display. A condensate heating element in the pan evaporates excess water, and a removable installation board gives easy access to the condenser coil for cleaning and service. On one-door models the door swing is field reversible.
| Doors | 1 |
|---|---|
| Shelves | 3 per door |
| Exterior Dimensions (W x D x H) | 29" x 32.2" x 82.5" |
| Interior Dimensions (W x D x H) | 24.4" x 27.1" x 59.8" |
| Temperature Range | -8°F to 0°F (-22°C to -18°C) |
| Refrigerant | R290 |
| Compressor Size | 2/3 HP |
| Amps | 4.2 A |
| Controls | Electronic thermostat, digital LED temperature display |
| Doors Feature | Locking, self-closing, hold open at 90 degrees |
| Exterior | 430 stainless steel |
| Interior | 201 stainless steel; floor 304 stainless steel |
| Casters | 4" (lockable in front) |
| Shipping Weight | 297 lb |
